3.5MM SINGLE MONO AND STEREO JACKS
JACKS AND PLUGS
FAX: 773 792-2129
* Please visit the product pages on our website for the most up-to-date product information
3.5MM SINGLE MONO AND STEREO JACKS
Switchcraft introduces a new series of 3.5mm jacks. These
low profile jacks come in a wide variety of circuits, both
2 and 3 conductor versions. Circuits include mono closed,
stereo open, stereo tip closed and ring open, and stereo
closed. The 35RASMT Series is available on tape and reel
only. Contact Switchcraft for exact dimensions of the reels.
They’re designed for use in today’s electronic equipment
that features remote speakers, headsets, and headphones.
117
While they are more compact than commonly used PC
mount phone jacks, they are still extremely durable. Jacks
come on tape and reel, 1K per reel.
FEATURES AND BENEFITS
? SMT mounting
? Tape and reel packaging
? Wide variety of circuits
APPLICATIONS
? Computer
? Video Cameras
? Personal/Portable Audio Devices
? Multimedia
SPECIFICATIONS
Electrical Current Rating: 3A
Contact Resistance: <50 mohms
Insulation Resistance: 100 mohms (min.)
Dielectric Withstanding Voltage: 250VAC @ 1 minute
MECHANICAL
Lifecycles: 5,000
Operating Temperature: -25°C to +85°C
MATERIAL
Housing: Black thermoplastic
Sleeve, Ring and Tip Terminals:
Copper Alloy, silver-plated
Shunt Terminal: Copper Alloy, Silver-plated
35RASMT
3.5MM SINGLE MONO
AND STEREO JACKS
Part Number/Description
35RASMT2AHNTR
Mono, closed circuit, on tape and reel
35RASMT2BHNTR
Stereo, dual open circuit,
on tape and reel
35RASMT3BHNTR
Stereo, tip closed and ring open
circuit, on tape and reel
35RASMT4BHNTR
Stereo, dual closed circuit,
on tape and reel
(See next page for drawings.)
DIMENSIONS ARE FOR REFERENCE ONLY
Inch
(mm)
SWITCHCRAFT, INC. 5555 N. Elston Ave. ? Chicago, IL 60630
